EXPIRED
BECOME STRUCTURAL ENGINEER IN JUST 3 HOURS
EVERY THING FROM ARCHITECTURAL DRAWING TO DESIGN SHEET USING
AutoCAD + CSI ETABS
DURATION
3 Hours (2 PM to 5 PM)
DATE
4th June 2023
LANGUAGE
English & Hindi
1st (60 Minutes)
2nd (60 Minutes)
In this time, we will initiate the work with ETABS software by setting out unit system, design codes, defining of material and section properties, defining of load patterns, and load combination. There after starting of modeling with modeling of columns, beams, slabs etc. In the end of this 2nd 60 minutes, we will assign the frame and shell loads.
3rd (60 Minutes)
In this last 60 minutes of this workshop, we will be making the model finally ready to go for analysis by checking all modeling errors and rectifying all that errors. Performing analysis and knowing stresses in each member and then performing design with ensuring that all the members passing the design checks. In the last of this 60 minute, we will give some bonus to all attenders of this workshop.
STEP - 01
Study about Architectural Drawing
Understanding of architectural drawing is the first step to proceed for the design of any proposed structure.
STEP - 02
Preliminary Sizing of All Elements
At the preliminary stage, it is needed to prepare structural framing plan for which it is needs to decide preliminary sizes of all structural elements as beams, columns, slabs shear wall etc.
STEP - 03
Preparing Structural Framing Plan
At the preliminary stage, it is needed to prepare structural framing plan for which it is needs to decide preliminary sizes of all structural elements as beams, columns, slabs shear wall etc.
STEP - 04
Initiating with FEM Based Software’s (i.e., CSI ETABS)
To initiate the projects in any FEM based software such as CSI ETABS, its needed to define all essentials as grids definition, material and section properties, unit system and code of design etc.
STEP - 05
Modeling in CSI ETABS
To have the idea about the response of structure under all the application of loading we need to create a model (Prototype) in software. The modeling will include modeling of columns, beams, slabs and shear wall etc.
STEP - 06
Analysis in CSI ETABS
After having model with all anticipated loads, it is needed to see what intensities of stresses (S.F, B.M, Torsion, Axial Force, etc.) are going to develop in each member. In respect of stresses developed, will plan to design that particular member.
STEP - 07
Design in CSI ETABS
Performing design in respect of particular design codes. Where it is needed to ensure all members are passing the design checks mean while it is also needed to optimized the design for economy as well as stability.
1️⃣ What is the flow of completion of any project from the prospective of structural engineer❓
2️⃣ What to do if I got any project from architect for design❓
3️⃣ How to read architectural drawings❓
4️⃣ How to decide preliminary sizes, positioning over architectural plan❓
5️⃣ What important things needed to take in consideration before sending framing plan to architect for approval❓
6️⃣ How to check and correct the model in CSI ETABS for all modeling errors❓
7️⃣ What to do if beams, columns, shear walls are failing in design checks, and what to do to make them safe in design❓
⭐⭐⭐⭐⭐ 4.96/5 Stars
1000+ Participants Rated this Workshop
If you are doing your bachelor in Civil Engineering or Master in Structural Engineering, & want to become structural engineer in future. So, this workshop will definitely help you to increase your knowledge and will give real exposure to how professionals are designing the structures by using ETABS software.
Those who are new in the field of structural engineer, they are normally having lack of knowledge & confidence about how to start and complete the design, schedule and detail of complete structure by using ETABS software.
Those who are working as site engineer and willing to change their work profile from Site Engineer to Design Engineer, they can also join this workshop.
Architect
Those who are working as architect very well and want to expands there expertise in designing, they can also join this workshop.
Mr. ZIYAURRAHMAN ANSARI
Asia’s Leading Corporate Trainer
7
Year of experience in training and coaching
5000
Students/professionals reached in the last 7 Years
30
Seminars And Workshops Conducted In The Last 7 Years
10K
Social Media Following
3000
Paid Customers
6+
Country Served
1. What if I have questions about registration, attending, etc?
You can drop us a mail to structureschool033@gmail.com. We will be happy to help you.
2. Why does this program cost only ₹49?
The fee is just to make sure to get a commitment from you that you will be there. It is not the value of the program. You can understand the true value of the program only after you attend it yourself.
3. Will I get the recording of the program?
This is a live program where Ziyaurrahman will be training. So no recording will be provided.
4. If I miss attending this time can I attend this again?
Yes, you may attend it again at a later date.
5. What do I need to keep handy during the webinar?
Just an open mind and a book to make a lot of notes.
